1. 5 advanced tips for using a tire inflation gun

Inflate cold tires: the key to accurately control pressure

Principle: When the temperature of the tire rises after driving, the internal air pressure will expand (the air pressure increases by about 3-4 kPa for every 10℃ increase). If the tire is inflated to the standard value when it is hot, the tire pressure will be low after cooling, resulting in increased fuel consumption and uneven tread wear.

Operation:

Inflate the vehicle after it has been stationary for at least 3 hours (or the vehicle has been driven no more than 2 kilometers).

Refer to the standard value of cold tires on the door frame or fuel tank cap (not the reading of hot tires).

Exception: In case of emergency inflation, the pressure can be slightly higher than the standard value by 5%, but it needs to be checked again after cooling.

Preset pressure + automatic stop: avoid damage to the tire due to overpressure

Tips:

When using a digital inflation gun, set the target pressure in advance (such as 2.5 bar for sedans), and stop automatically after the preset value is reached to prevent overpressure caused by human misjudgment.

Inflator guns without automatic stop function need to be equipped with mechanical pressure gauges, and stop and check in sections during inflation (stop every 0.3 bar).

Risks: Overpressure will accelerate the wear of the center of the tread and even cause a blowout; low pressure will increase shoulder wear and fuel consumption.

Valve treatment: prevent air leakage and extend life

Cleaning: Unscrew the dust cap of the valve before inflation and use a toothbrush to clean the dust inside (sand may cause slow leakage).

Seal:

After the inflation gun nozzle is aimed at the valve core, press down and rotate half a circle to ensure a tight fit (avoid the "hissing" sound of air leakage).

After inflation, apply silicone-based grease to the valve core thread to prevent metal oxidation from causing jamming.

The "golden angle" of the inflation gun: improve efficiency and safety

Incorrect operation: The inflation gun is 90° perpendicular to the valve nozzle, which can easily lead to unstable connection or airflow obstruction.

Correct posture:

The gun body is at an angle of 30°-45° to the side of the tire, which makes the airflow smoother and increases the inflation speed by 20%.

Heavy vehicles (such as trucks) need to be held with both hands to avoid recoil damage to the valve nozzle.

Inflation strategies in winter and summer

Winter:

For every 10℃ drop in temperature, the tire pressure drops by about 7 kPa. It is necessary to inflate 0.2-0.3 bar more than the standard value to compensate for low-temperature shrinkage.

Preferably use an antifreeze inflation gun (such as models with built-in heating function) to prevent condensed water from freezing and blocking the airway.

Summer:

Avoid inflating during high temperature periods (such as noon), as the tire pressure may be artificially high due to the ambient temperature.

After inflation, let it stand for 10 minutes and then retest to eliminate the influence of thermal expansion.



2. Tire Inflation Gun Maintenance Guide: Key Maintenance Steps to Extend Service Life

• Clean the air nozzle and airway regularly (once a week)

Problem: Dust and oil block the airway, resulting in slow inflation or unstable pressure.

Maintenance method:

Use compressed air to reversely purge the airway of the air gun (operate after removing the air nozzle).

Clean the inside of the air nozzle with a cotton swab + alcohol to remove sludge (especially for models connected to oil-containing air compressors).

Note: Avoid water washing to prevent the internal sensor from getting wet.



• Check the seal and O-ring (once a month)

Problem: Aging of the seal will cause leakage and pressure cannot be maintained.

Maintenance method:

Disassemble the head of the air gun and check the valve seal and the O-ring at the air pipe connection.

If cracks or deformation are found, replace them immediately (silicone material is more resistant to high temperatures).

Lubrication: Apply a small amount of silicone-based grease to extend the life of the seal.



• Calibrate the pressure sensor (once every 6 months)

Problem: After long-term use, the pressure reading drifts.

Calibration method:

Compare the test using a standard pressure gauge.

If the error exceeds ±0.1 bar, follow the instructions to enter the calibration mode for adjustment (digital display models usually require long pressing of the SET button).

Note: Before calibration, the residual air pressure in the gun needs to be emptied.



• Lubricate the internal mechanical structure (once every 3 months)

Problem: The piston or spring is dry, causing the trigger to jam and difficulty in inflating.

Maintenance method:

Remove the housing and apply light lubricating oil to the moving parts (such as levers and piston rods).

Taboo: Ordinary butter is prohibited, as it is easy to adhere to dust at high temperatures.



• Correct storage and rust prevention

Problem: Random stacking leads to bumps and rust.

Maintenance method:

Empty the internal condensed water before storage (especially in humid environments).

Spray rust inhibitor on metal parts.

Use a special bracket to hang to avoid bending of the air pipe.



• Regularly replace wearing parts (as needed)

Parts	Replacement cycle	Symptoms
Nose seal	1 year or when leaking	"Hissing" sound when inflating
Pressure sensor	3-5 years	Reading jumps or cannot be zeroed
Trachea	2 years or when cracked	Inflation pressure is unstable
Battery (wireless model)	2 years	Battery life is significantly reduced



3. How to improve the efficiency of industrial tire inflation guns?

Valve core pretreatment

Efficient operation:

Use the valve core wrench to loosen the core rod 1/4 turn before inflation (reduce air flow resistance)

Tighten after inflation is completed



High-pressure and high-flow gas system

Technical parameters:

Working pressure ≥10 bar (only 3-5 bar for ordinary models)

Flow ≥50 L/min (about 20 L/min for ordinary models)

Efficiency improvement:

Truck tire inflation time is shortened from 15 minutes to 3-5 minutes

Applicable scenarios: ultra-high pressure requirements such as mining tires and construction machinery



Dual-channel inflation technology

Principle: Connect two inflation tubes at the same time to inflate the double-wheeled tires (such as trailer axles) synchronously

Measured data:

Traditional single-gun inflation of double wheels takes 20 minutes, dual-channel inflation takes only 8 minutes (efficiency increased by 60%)
